Materials
99.8% of the products sold by Arnev Products, Inc. are manufactured here in the USA.
All Painted Finished Switch Plates
Manufactured from .042 cold roll steel, then powder painted in 600-degree ovens for a scratch-resistant finish for years of use.
(White-Almond-Ivory-Bronze-Terra-Cotta-Sand Tex-Pewter-Matte Black-Shiny Black-Hammered Copper)
Custom hand-crafted finishes for our Copper Patina, and Marbleware manufactured in the USA.
Stainless Steel - .036 gauge 304 #4PL with lacquer protective coating
Brushed Nickel - .036 gauge metal, lightly brushed with protective lacquer coating
Solid Brass - .042 gauge, lightly brushed finish with protective lacquer coating
Brass on metal - .036 gauge lightly brushed finish with protective lacquer coating
Chrome on metal - .036 gauge, mirror finish with no brush strokes, protective lacquer coating
Copper on metal - .036 gauge, brushed strokes, protective coating
Mirrored Glass, Clear Glass, Frosted Glass, Gray Glass Switch Plates
All are real glass, approximately 3/16th thick.
Manufactured in the USA with a powder resin and then baked in the ovens for a real stone feel.
Manufactured in the USA with Acrylic materials in clear and mirrored finishes. 1/8th in thick and in many sizes.
Unfinished Wooden Switch Plates
Manufactured in the USA with 95 different wood types and 84 standard configurations.
Corner Custom Designed Switch Plates with Custom Finishes to match our cabinet hardware
Available in 38 custom finishes and all made in the USA. .042 Guage metal and the corners match the cabinet hardware designs. These are all made-to-order products.
|
Metal Switchplate sizing: |
|||||||||
|
* For Glass Mirrored & Custom Wood, see below* |
|||||||||
| One gang switch plates (Singles-A, Single Outlets-B, Single Groundfaults-F) |
3 " wide by 5 " high | ||||||||
| Two gang switch plates (Doubles-C, Combo's-D, Double Groundfaults-K, etc.) |
4 7/8" wide by 5 " high | ||||||||
| Three gang switch plates (Triples-E, Triple Groundfaults-J, Groundfault/Double Switch-Q, etc.) |
6 11/16" wide by 5 " high | ||||||||
| Four gang switch plates (Quad Switches-L, Outlet Cover/Triple Switch-O, etc.) |
8 1/2" wide by 5 " high | ||||||||
| Five gang switch plates (5-Switch-5S, 5-Groundfault/Rocker-5 GF/R) |
10 5/16" wide by 5 " high | ||||||||
| Six gang switch plates (6-Switch-6S, 6-Groundfault/Rocker-6 GF/R) |
12 1/16" wide by 5 " high | ||||||||
| Seven gang switch plates (7-Switch-7S, 7-Groundfault/Rocker-7 GF/R) |
13 7/8" wide by 5 " high | ||||||||
| Eight gang switch plates (8-Switch-8S, 8-Groundfault/Rocker-8 GF/R) |
15 3/4" wide by 5 " high | ||||||||
|
Glass Mirrored/Frosted Glass/Clear Glass sizing: |
|||||||||
| One gang switchplates (Singles-A, Single Outlets-B, Single Groundfaults-F, Single Blanks, etc.) |
3 1/2" wide by 5 1/4" high | ||||||||
| Two gang switchplates (Doubles-C, Combo's-D, Double Groundfaults-K, Double blanks, etc.) |
5 1/4" wide by 5 1/4" high | ||||||||
| Three gang switchplates (Triples-E, Triple Groundfaults-J, Groundfault/Double Switch-Q, etc.) |
7 1/4" wide by 5 1/4" high | ||||||||
| Four gang switchplates (Quad Switches-L, Outlet Cover/Triple Switch-O, etc.) |
9" wide by 5 1/4" high | ||||||||
| Five gang switchplates (5-Switch-5S, 5-Groundfault/Rocker-5 GF/R) |
11" wide by 5 1/4" high | ||||||||
| Six gang switchplates (6-Switch-6S, 6-Groundfault/Rocker-6 GF/R) |
12 5/8" wide by 5 1/4" high | ||||||||
|
Acrylic Mirrored Switchplate Sizes
Singles-A, Single Outlets-B, Single Groudfaults-F, Single Blanks are 5-1/4" tall x 3 1/2" wide
Doubles-C, Combo's-D, Double Groundfaults, etc are 5-1/4" x 5-1/4" Triple sizes E, Triple Groundfaults-J, Groundfault/Double Switch-Q, etc. are 6" tall x 7-13/16" wide Four gang sizes like Quad switches-L, Outlet Cover/Triple Switch-O, etc. are 6" tall x 9-5/8" wide
Five gang sizes like 5S, 5GF/R, etc. are 6" tall x 11-1/2" wide
Six gang sizes like 6S, 6GF/R, etc. are 6" tall x 13-1/4" wide
|
|||||||||
|
Custom Wood Switchplate sizing: |
|||||||||
| One gang switchplates (Singles, Single Outlets, Single Groundfaults, Single Blanks, etc.) |
3 3/16" wide by 5" high | ||||||||
|
Two gang switchplates |
5" wide by 5" high | ||||||||
|
Three gang switchplates |
6 13/16" wide by 5" high | ||||||||
|
Four gang switchplates |
9" wide by 5" high | ||||||||
|
Five gang switchplates |
10 13/16" wide by 5" high | ||||||||
|
Six gang switchplates |
12 5/8" wide by 5" high | ||||||||
|
Seven gang switchplates |
14 7/16" wide by 5" highlight | ||||||||
|
Eight gang switchplates |
16 1/4" wide by 5" high | ||||||||
|
All custom wood sizes are + or - 3/16" and about 1/4 inch thick, much like a regular plastic switchplate.
SCREWLESS WOOD SWITCH PLATE SIZES
Please Note: All screwless wallplates are 1/2 inches wider, and 3/4 inches taller than our standard sizes in one-two-three and four gang plates. This is to accommodate the necessary backing structure needed for this type of installation.
All custom wood sizes are about 1/4 inch thick, much like a regular plastic switchplate.
Single size is 5-3/4" tall by 3-1/2" wide
Double size is 5-3/4" tall by 5-3/4" wide
Triple size is 5-3/4" tall by 7-1/2" wide
Quad size is 5-3/4" tall by 9’’ wide
Stonique custom stone switchplate sizes
|
|||||||||
