Metal Switchplate sizing:
|
|
* For Glass Mirrored & Custom Wood, see below*
|
One gang switch plates
(Singles-A, Single Outlets-B, Single Groundfaults-F) |
3 " wide by 5 " high |
Two gang switch plates
(Doubles-C, Combo's-D, Double Groundfaults-K, etc.) |
4 7/8" wide by 5 " high |
Three gang switch plates
(Triples-E, Triple Groundfaults-J, Groundfault/Double Switch-Q, etc.) |
6 11/16" wide by 5 " high |
Four gang switch plates
(Quad Switches-L, Outlet Cover/Triple Switch-O, etc.) |
8 1/2" wide by 5 " high |
Five gang switch plates
(5-Switch-5S, 5-Groundfault/Rocker-5 GF/R) |
10 5/16" wide by 5 " high |
Six gang switch plates
(6-Switch-6S, 6-Groundfault/Rocker-6 GF/R) |
12 1/16" wide by 5 " high |
Seven gang switch plates
(7-Switch-7S, 7-Groundfault/Rocker-7 GF/R) |
13 7/8" wide by 5 " high |
Eight gang switch plates
(8-Switch-8S, 8-Groundfault/Rocker-8 GF/R) |
15 3/4" wide by 5 " high |
| |
|
Glass Mirrored/Frosted Glass/Clear Glass sizing:
|
|
|
One gang switchplates
(Singles-A, Single Outlets-B, Single Groundfaults-F, Single Blanks, etc.) |
3 1/2" wide by 5 1/4" high |
Two gang switchplates
(Doubles-C, Combo's-D, Double Groundfaults-K, Double blanks, etc.) |
5 1/4" wide by 5 1/4" high |
Three gang switchplates
(Triples-E, Triple Groundfaults-J, Groundfault/Double Switch-Q, etc.) |
7 1/4" wide by 5 1/4" high |
Four gang switchplates
(Quad Switches-L, Outlet Cover/Triple Switch-O, etc.) |
9" wide by 5 1/4" high |
Five gang switchplates
(5-Switch-5S, 5-Groundfault/Rocker-5 GF/R) |
11" wide by 5 1/4" high |
Six gang switchplates
(6-Switch-6S, 6-Groundfault/Rocker-6 GF/R) |
12 5/8" wide by 5 1/4" high |
|
Acrylic Mirrored Switchplate Sizes
Singles-A, Single Outlets-B, Single Groudfaults-F, Single Blanks are 5-1/4" tall x 3 1/2" wide
Doubles-C, Combo's-D, Double Groundfaults, etc are 5-1/4" x 5-1/4"
Triple sizes E, Triple Groundfaults-J, Groundfault/Double Switch-Q, etc. are 6" tall x 7-13/16" wide
Four gang sizes like Quad switches-L, Outlet Cover/Triple Switch-O, etc. are 6" tall x 9-5/8" wide
Five gang sizes like 5S, 5GF/R, etc. are 6" tall x 11-1/2" wide
Six gang sizes like 6S, 6GF/R, etc. are 6" tall x 13-1/4" wide
|
|
Custom Wood Switchplate sizing:
|
| |
One gang switchplates
(Singles, Single Outlets, Single Groundfaults, Single Blanks, etc.) |
3 3/16" wide by 5" high |
Two gang switchplates
(Doubles, Combos, Double Groundfaults, Double blanks, etc.) |
5" wide by 5" high |
Three gang switchplates
(Triples, Triple Groundfaults, Groundfault/Double Switch, etc.) |
6 13/16" wide by 5" high |
Four gang switchplates
(Quad Switches, Outlet Cover/Triple Switch, etc.) |
9" wide by 5" high |
Five gang switchplates
(5-Switch, 5-Groundfault/Rocker, etc.) |
10 13/16" wide by 5" high |
Six gang switchplates
(6-Switch, 6-Groundfault/Rocker, etc.) |
12 5/8" wide by 5" high |
Seven gang switchplates
(7-Switch, 7-Groundfault/Rocker, etc.) |
14 7/16" wide by 5" highlight |
Eight gang switchplates
(8-Switch, 8-Groundfault/Rocker, etc.) |
16 1/4" wide by 5" high |
